Engine Specifications
| Propshaft Rated Horsepower | 135hp (101kw) |
|---|---|
| Max RPM at Full Throttle | 5200-6400 |
| Cylinders | Straight-4, 16-valve, direct acting double overhead cam (DOHC) |
| Displacement | 105.7 cu in. (1.7lt) (1732cc) |
| Induction System | Supercharged with charge air cooling and electronic boost pressure control |
| Fuel System | Computer-controlled multi-port Electronic Fuel Injection (EFI) |
| Fuel Requirements | Unleaded regular 87-octane minimum (R+M/2) |
| Ignition System | SmartCraft PCM 03 digital inductive |
| Charging System | Fully regulated belt-driven 70-amp (882-watt) |
| Cooling System | Water-cooled with thermostat & pressure control |
| Lubrication System | Integrated dry slump |
| Oil Requirement | NMMA – certified FCW SAE 25W-40 |
| Engine Management System | SmartCraft PCM 03 |
| Engine Control & Gear Shift | SmartCraft Digital Throttle & Shift (DTS) |
| Engine Protection System | SmartCraft Engine Guardian |
| Gear Ratio | 2.08:1 |
| Driveshaft Lengths | 20″(L); 25″(XL,CXL) |
| Trim / Tilt Sytem | Power trim and tilt with SmartCraft-programmable tilt |
| Maxium Tilt Range | 73 degree (-5 degree to 68 degree) (as measured a 14 degree tramsom) |
| Counter rotation | Available on 25″ (CXL) models |
| Steering System | Hydraulic or electro-hydraulic power steering available using standard Mercury universal cylinder |
| Comparative Weight | 20″ (L) 231kg 510lbs, 25″ XL 239kg 527lbs; |
