Engine Specifications
HP/Kw @ Prop | 200 / 149 |
---|---|
Full throttle RPM | 5800-6400 |
Cylinder Configuration | 4 (in-line) |
Displacement (L / CID) | 105.7 / 1732 |
Bore and Stroke (in / mm) | 3.23 x 3.23in 82 x 82mm |
Fuel Induction System | SmartCraft DTS 4 valves per cylinder dual overhead cam (DOHC) |
Ignition | SmartCraft PCM Digital Inductive |
Fuel System | Electronic Fuel Injection (EFI) |
Alternator Amp | 70 amp / 882 watt (Belt-Driven) |
Cooling System | Water-cooled with thermostat |
Starting | SmartCraft electric (turn-key) |
Gearcase Ratio | 2.08:1 |
Gear Shift | SmartCraft DTS F-N-R |
Steering | Big Tiller Compatible Hydraulic Mercury power steering (optional) |
Trim System | SmartCraft programmable |
Exhaust System | Though prop |
Shallow water trim range (degrees) | 20 |
Recommended Oil | Mercury Verado Oil |
Fuel Ethanol Tolerance | 87 octane/up to 10% ethanol |
Remote fuel tank optional | Yes |
Engine Protection Operator Warning System | SmartCraft Engine Guardian |
Compatible with Smartcraft Digital Technology | Yes |
Shaft Length | 20 in (508 mm) 25 in (635mm) |
Dry Weight * Lightest model available | 510lbs / 231kg |
