Engine Specifications
| HP/Kw @ Prop | 300 / 224 |
|---|---|
| Full throttle RPM | 5800-6400 |
| Cylinder Configuration | 6 (in-line) |
| Displacement (L / CID) | 158.5 / 2598 |
| Bore and Stroke (in / mm) | 3.23 x 3.23in 82 x 82mm |
| Fuel Induction System | SmartCraft DTS 4 valves per cylinder dual overhead cam (DOHC) |
| Ignition | SmartCraft PCM Digital Inductive |
| Fuel System | Electronic Fuel Injection (EFI) |
| Alternator Amp | 70 amp / 882 watt (Belt-Driven) |
| Cooling System | Water-cooled with thermostat |
| Starting | SmartCraft electric (turn-key) |
| Gearcase Ratio | 1.75:1 |
| Gear Shift | SmartCraft DTS F-N-R |
| Steering | Mercury power steering |
| Trim System | SmartCraft programmable |
| Exhaust System | Though prop |
| Shallow water trim range (degrees) | 20 |
| Recommended Oil | Mercury Verado Oil |
| Fuel Ethanol Tolerance | 87 octane/up to 10% ethanol |
| Remote fuel tank optional | Yes |
| Engine Protection Operator Warning System | SmartCraft Engine Guardian |
| Compatible with Smartcraft Digital Technology | Yes |
| Shaft Length | 20 in (508 mm) 25 in (635mm) 30 in (762mm) |
| Dry Weight * Lightest model available | 635lbs / 288kg |
